Quantum 25

Quantum 25 kN is the product of state of the art design, built to the highest quality levels and has many advanced technical features

Programming tests and monitoring results can be controlled through our powerful and Intelligent Labtest test software, which allows complete and accurate data management in accordance with European, North American and International Standards.

This instrument is suitable for use both in production lines where the operator has to be fast and efficient and can accurately control the test with the optional remote control unit and also laboratory environments where the advanced software lets users analyse the test data. Labtest allows full control of processing, filing, managing, and transmitting data to the company network, database, and performs many other functions.

This Quantum frame has a flexible and modular construction. It can be equipped with various grips and fixtures, as well as extensometers, additional load cells, temperature chambers and many more accessories, for a wide range of applications (tensile, compression, flexure, etc.). In addition, this user-friendly instrument can be fitted with additional load cells with lower capacities, providing the highest resolution and accuracy for microloads.

  • Two-column rigid system with 25 kN maximum capacity
  • Suitable for metals, plastics, composites and other materials
  • Stylish design and advanced features
  • Ergonomic and design
  • Flexible and modular design for easy future expansion
  • Key technical advantages include extremely high resolution of load andstroke readings,
    as well as minimum test speed of 0.0005 mm/min, for
    high performances
    and accurate results
  • Manufactured by an ISO 9001 certified company
  • Excellent price-to-quality ratio


Capacity of frame and max allowed load 25,000 N (5,620 lbf)
Load cell nominal size
(tensile & compression)
25,000 N
Standards met or exceeded ISO 7500-1, ASTM E4, EN 10002-2, JIS B7721, GB/T 16825.1, DIN 51221, BS 1610 and other equivalent
Testing area depth Unlimited
Power Rating 700 W
Machine weight (without accessories) 160 Kg (353 lb)
Finishing Silver RAL 9006 / Black RAL 9011
PC interface Ethercat (A dedicated Ethernet port on PC is required)
Noise level

< 72 db


Height 1,548 mm
Width 730 mm
Depth 700 mm
